Product Description

1. Wire gauge 0.11mm to 16mm

2. Surface finish: bright, matt, electrolysis bright

3. Grade: 200,300.400 600(631) series

4. Stainless steel wire

1) Supplying good elongation generator for other manufactures of filament drawing,

2) producing fine spring wire. acupuncture wire and pressed wire, etc.

3)200 series,300series,400series

4) mesh, belt, bright finish


Product Instructions:

1) Grade: 201, 202, 301, 302, 304, 304L, 316, 316L etc.,

2) Standard: AISI, ASTM,  GB,  SUS

2) Diameter: 0.01-4.0mm

3) Condition: round wire, bright

4) Surface finish: bright, matt, and downy

5) Packing:Woven bag, coil, others are also available according to client' requirement

2. Chemical Composition about stainless steel coil

GradeCSiMnPSNiCrMo
201≤0.15≤0.755.5-7.5≤0.06≤0.033.5-5.516.0-18.0-
202≤0.15≤1.07.5-10.0≤0.06≤0.034.-6.017.0-19.0-
301≤0.15≤1.0≤2.0≤0.045≤0.036.0-8.016.0-18.0-
302≤0.15≤1.0≤2.0≤0.035≤0.038.0-10.017.0-19.0-
304≤0.08≤1.0≤2.0≤0.045≤0.038.0-10.518.0-20.0-
304L≤0.03≤1.0≤2.0≤0.035≤0.039.0-13.018.0-20.0-
309S≤0.08≤1.0≤2.0≤0.045≤0.0312.0-15.022.0-24.0-
310S≤0.08≤1.5≤2.0≤0.035≤0.0319.0-22.024.0-26.0-
316≤0.08≤1.0≤2.0≤0.045≤0.0310.0-14.016.0-18.02.0-3.0
316L≤0.03≤1.0≤2.0≤0.045≤0.0312.0-15.016.0-18.02.0-3.0
321≤0.08≤1.0≤2.0≤0.035≤0.039.0-13.017.0-19.0-
630≤0.07≤1.0≤1.0≤0.035≤0.033.0-5.015.5-17.5-
631≤0.09≤1.0≤1.0≤0.030≤0.0356.50-7.7516.0-18.0-
904L≤2.0≤0.045≤1.0≤0.035-23.0-28.019.0-23.04.0-5.0
2205≤0.03≤1.0≤2.0≤0.030≤0.024.5-6.522.0-23.03.0-3.5
2507≤0.03≤0.80≤1.2≤0.035≤0.026.0-8.024.0-26.03.0-5.0
2520≤0.08≤1.5≤2.0≤0.045≤0.030.19-0.220.24-0.26-
410≤0.15≤1.0≤1.0≤0.035≤0.03-11.5-13.5-
430≤0.12≤0.75≤1.0≤0.040≤0.03≤0.6016.0-18.0
